CAP ALUM 3.3UF 20% 400V RADIAL
ULD2G3R3MPD6TD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 3.3UF 20% 400V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can.
In Stock: 3,235
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 3.3 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 48 mA @ 120 Hz |
| Ripple Current @ High Frequency | 96 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.433" (11.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
ULD2G3R3MPD6TD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| UPJ2V3R3MPD1TD | Nichicon | CAP ALUM 3.3UF 20% 350V RADIAL | 91% | View |
| UPJ2V3R3MPD | Nichicon | CAP ALUM 3.3UF 20% 350V RADIAL | 91% | View |
| 600D335F250KD4 | Vishay Sprague | CAP ALUM 3.3UF 250V AXIAL | 70% | View |
| EKMQ251ELL3R3MF11D | United Chemi-Con | CAP ALUM 3.3UF 20% 250V RADIAL | 65% | View |
| 50YXM3.3MEFR5X11 | Rubycon | CAP ALUM 3.3UF 20% 50V RADIAL | 60% | View |
| EKMQ500ELL3R3ME11D | United Chemi-Con | CAP ALUM 3.3UF 20% 50V RADIAL | 53% | View |
Submit your RFQ for ULD2G3R3MPD6TD and get a quote within 24 hours.
