CAP ALUM 12UF 20% 200V RADIAL
ULD2D120MPD1TD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 12UF 20% 200V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can.
In Stock: 6,161
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 12 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 88 mA @ 120 Hz |
| Ripple Current @ High Frequency | 167.2 mA @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.197" (5.00mm) |
| Size / Dimension | 0.394" Dia (10.00mm) |
| Height - Seated (Max) | 0.433" (11.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
ULD2D120MPD1TD is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKXE201ELL120MH15D | United Chemi-Con | CAP ALUM 12UF 20% 200V RADIAL TH | 93% | View |
| 250LEX12MEFC10X12.5 | Rubycon | CAP ALUM 12UF 20% 250V RADIAL | 89% | View |
| UPJ1J120MDD1TD | Nichicon | CAP ALUM 12UF 20% 63V RADIAL | 71% | View |
| 80ZLJ12MT15X11 | Rubycon | CAP ALUM 12UF 20% 80V RADIAL | 70% | View |
| 80ZLH12MEFC5X11 | Rubycon | CAP ALUM 12UF 20% 80V RADIAL | 63% | View |
| 126KXM100M | Cornell Dubilier / Illinois Capacitor | CAP ALUM 12UF 20% 100V RADIAL | 50% | View |
Submit your RFQ for ULD2D120MPD1TD and get a quote within 24 hours.
