CAP ALUM 10UF 20% 100V RADIAL
UKW2A100MED is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 10UF 20% 100V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 100 V, package / case Radial, Can.
In Stock: 3,867
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 10 µF |
| Tolerance | ±20% |
| Voltage - Rated | 100 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 75 mA @ 120 Hz |
| Ripple Current @ High Frequency | 150 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.098" (2.50mm) |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.433" (11.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UKW2A100MED is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MALREKB00AA210L00K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 10UF 20% 100V RADIAL | 91% | View |
| UKL1J100KED | Nichicon | CAP ALUM 10UF 10% 63V RADIAL | 86% | View |
| UVK2C100MPD | Nichicon | CAP ALUM 10UF 20% 160V RADIAL | 80% | View |
| 200PK10MEFC8X11.5 | Rubycon | CAP ALUM 10UF 20% 200V RADIAL | 72% | View |
| TVX2E100MCD1LW | Nichicon | CAP ALUM 10UF 20% 250V AXIAL | 70% | View |
| B43866F2106M | EPCOS - TDK Electronics | CAP ALUM 10UF 20% 250V RADIAL | 70% | View |
Submit your RFQ for UKW2A100MED and get a quote within 24 hours.
