CAP ALUM 33UF 20% 63V RADIAL
UKW1J330MED1TA is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 33UF 20% 63V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 63 V, package / case Radial, Can.
In Stock: 9,864
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 140 mA @ 120 Hz |
| Ripple Current @ High Frequency | 280 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.098" (2.50mm) |
| Size / Dimension | 0.248" Dia (6.30mm) |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UKW1J330MED1TA is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 515D336M063AA6AE3 | Vishay Sprague | CAP ALUM 33UF 20% 63V RADIAL | 100% | View |
| UBT1H330MPD1TD | Nichicon | CAP ALUM 33UF 20% 50V RADIAL | 90% | View |
| 336TTA050M | Cornell Dubilier / Illinois Capacitor | CAP ALUM 33UF 20% 50V AXIAL | 77% | View |
| UBW2A330MPD1TD | Nichicon | CAP ALUM 33UF 20% 100V RADIAL | 60% | View |
| 500LXW33MEFR12.5X30 | Rubycon | CAP ALUM 33UF 20% 500V RADIAL | 56% | View |
| 10ZLG33MEFCT55X7 | Rubycon | CAP ALUM 33UF 20% 10V RADIAL | 54% | View |
