CAP ALUM 2200UF 20% 50V RADIAL
UKT1H222MHD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 2200UF 20% 50V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can.
In Stock: 8,057
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 2200 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 1.47 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.691 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.630" Dia (16.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UKT1H222MHD is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKMQ500ELL222MLN3S | United Chemi-Con | CAP ALUM 2200UF 20% 50V RADIAL | 96% | View |
| EKMQ630ELL222MMP1S | United Chemi-Con | CAP ALUM 2200UF 20% 63V RADIAL | 89% | View |
| 35WXA2200MEFC18X20 | Rubycon | CAP ALUM 2200UF 20% 35V RADIAL | 79% | View |
| MAL224660222E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 2200UF 20% 35V RADIAL | 72% | View |
| EKMQ250ELL222MK25S | United Chemi-Con | CAP ALUM 2200UF 20% 25V RADIAL | 63% | View |
| ECA-1CHG222 | Panasonic Electronic Components | CAP ALUM 2200UF 20% 16V RADIAL | 56% | View |
