CAP ALUM 33UF 20% 50V RADIAL
UKA1H330MDD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 33UF 20% 50V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 50 V, package / case Radial, Can.
In Stock: 9,352
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 33 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 90 mA @ 120 Hz |
| Ripple Current @ High Frequency | 180 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.079" (2.00mm) |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UKA1H330MDD is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EKMG500EC3330ME11D | United Chemi-Con | CAP ALUM 33UF 20% 50V RADIAL | 97% | View |
| EKMQ500ELL330ME11D | United Chemi-Con | CAP ALUM 33UF 20% 50V RADIAL | 97% | View |
| UPJ1H330MED1TD | Nichicon | CAP ALUM 33UF 20% 50V RADIAL | 83% | View |
| UVZ1V330MDH | Nichicon | CAP ALUM 33UF 20% 35V RADIAL | 80% | View |
| EEU-FC1H330B | Panasonic Electronic Components | CAP ALUM 33UF 20% 50V RADIAL | 76% | View |
| EV336M025A9GAAKPLP | KEMET | ALUM ELECTRO CAP | 57% | View |
