CAP ALUM 220UF 20% 25V RADIAL
UKA1E221MPD1TD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 220UF 20% 25V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can.
In Stock: 4,693
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 220 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 240 mA @ 120 Hz |
| Ripple Current @ High Frequency | 360 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.138" (3.50mm) |
| Size / Dimension | 0.315" Dia (8.00mm) |
| Height - Seated (Max) | 0.512" (13.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UKA1E221MPD1TD is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B41866C5227M008 | EPCOS - TDK Electronics | CAP ALUM 220UF 20% 25V RADIAL | 94% | View |
| EKMG350ELL221MHB5D | United Chemi-Con | CAP ALUM 220UF 20% 35V RADIAL | 84% | View |
| MAL216050221E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 220UF 20% 35V RADIAL | 78% | View |
| MALREKB00BA322DL0K | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 220UF 20% 16V RADIAL | 76% | View |
| ELXY100ELL221MF15D | United Chemi-Con | CAP ALUM 220UF 20% 10V RADIAL | 72% | View |
| 860080574011 | Würth Elektronik | CAP ALUM 220UF 20% 35V RADIAL | 53% | View |
Submit your RFQ for UKA1E221MPD1TD and get a quote within 24 hours.
