CAP ALUM 47UF 20% 6.3V RADIAL
UKA0J470MDD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 47UF 20% 6.3V RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage - rated 6.3 V, package / case Radial, Can.
In Stock: 619
| Attribute | Value |
|---|---|
| Product Status | Not For New Designs |
| Capacitance | 47 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 65 mA @ 120 Hz |
| Ripple Current @ High Frequency | 130 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.079" (2.00mm) |
| Size / Dimension | 0.197" Dia (5.00mm) |
| Height - Seated (Max) | 0.492" (12.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
UKA0J470MDD is Not For New Designs. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EEA-GA1A470 | Panasonic Electronic Components | CAP ALUM 47UF 20% 10V RADIAL | 80% | View |
| UST1A470MDD1TE | Nichicon | CAP ALUM 47UF 20% 10V RADIAL | 74% | View |
| MAL212384479 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 47UF 20% 10V AXIAL | 73% | View |
| UPJ1C470MDD1TD | Nichicon | CAP ALUM 47UF 20% 16V RADIAL | 66% | View |
| UPS1A470MDD1TA | Nichicon | CAP ALUM 47UF 20% 10V RADIAL | 60% | View |
| 678D476M063CC4D | Vishay Sprague | CAP ALUM 47UF 20% 63V RADIAL | 56% | View |
Submit your RFQ for UKA0J470MDD and get a quote within 24 hours.
