CAP ALUM 470UF 20% 200V RADIAL
UCY2D471MHD is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 470UF 20% 200V RADIAL. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can.
In Stock: 2,837
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 470 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 12000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.85 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.7 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | 0.295" (7.50mm) |
| Size / Dimension | 0.709" Dia (18.00mm) |
| Height - Seated (Max) | 1.634" (41.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43504A477M60 | EPCOS - TDK Electronics | CAP ALUM 470UF 20% 420V SNAP | 69% | View |
| B43515B0477M | EPCOS - TDK Electronics | CAP ALUM 470UF 20% 420V SNAP | 65% | View |
| B43545B9477M000 | EPCOS - TDK Electronics | CAP ALUM 470UF 20% 400V SNAP | 60% | View |
| 672D477F020EK5D | Vishay Sprague | CAP ALUM 470UF 20V RADIAL | 58% | View |
| 10ZLG470MEFCT78X9 | Rubycon | CAP ALUM 470UF 20% 10V RADIAL | 56% | View |
| 30D477M035DD5A | Vishay Sprague | CAP ALUM 470UF 20% 35V AXIAL | 56% | View |
Submit your RFQ for UCY2D471MHD and get a quote within 24 hours.
