CAP ALUM 6800UF 20% 63V SNAP
LLS1J682MELC is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 6800UF 20% 63V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 63 V, package / case Radial, Can - Snap-In.
In Stock: 8,038
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 6800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 4.44 A @ 120 Hz |
| Ripple Current @ High Frequency | 5.106 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ESMH630VNN682MQ50U | United Chemi-Con | CAP ALUM 6800UF 20% 63V SNAP | 99% | View |
| EKMH630VSN682MR50W | United Chemi-Con | CAP ALUM 6800UF 20% 63V SNAP | 92% | View |
| EKMH630VSS682MR50U | United Chemi-Con | CAP ALUM 6800UF 20% 63V SNAP | 92% | View |
| LKS1K682MESB | Nichicon | CAP ALUM 6800UF 20% 80V SNAP | 89% | View |
| 688CKS025MQY | Cornell Dubilier / Illinois Capacitor | CAP ALUM 6800UF 20% 25V RADIAL | 58% | View |
| 860160280048 | Würth Elektronik | CAP ALUM 6800UF 20% 10V RADIAL | 54% | View |
Submit your RFQ for LLS1J682MELC and get a quote within 24 hours.
