CAP ALUM 15000UF 20% 50V SNAP
LLS1H153MELC is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 15000UF 20% 50V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 50 V, package / case Radial, Can - Snap-In.
In Stock: 3,638
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 15000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 6.56 A @ 120 Hz |
| Ripple Current @ High Frequency | 7.544 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.850" (47.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ESMH500VSN153MA45U | United Chemi-Con | CAP ALUM 15000UF 20% 50V SNAP | 98% | View |
| SLPX153M050H4P3 | Cornell Dubilier Electronics (CDE) | CAP ALUM 15000UF 20% 50V SNAP | 98% | View |
| 380LQ153M035K042 | Cornell Dubilier Electronics (CDE) | CAP ALUM 15000UF 20% 35V SNAP | 81% | View |
| 35USC15000MEFCSN25X50 | Rubycon | CAP ALUM 15000UF 20% 35V SNAP | 77% | View |
| MAL205657153E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 15000UF 20% 40V SNAP | 75% | View |
| 381LQ153M035J452 | Cornell Dubilier Electronics (CDE) | CAP ALUM 15000UF 20% 35V SNAP | 64% | View |
Submit your RFQ for LLS1H153MELC and get a quote within 24 hours.
