CAP ALUM 270UF 20% 400V SNAP
LKX2G271MESB35 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 270UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In.
In Stock: 7,302
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 270 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 1.22 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.7446 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LKX2G271MESA45 | Nichicon | CAP ALUM 270UF 20% 400V SNAP | 100% | View |
| B43252B9277M | EPCOS - TDK Electronics | CAP ALUM 270UF 20% 400V SNAP | 98% | View |
| LGNW6271MELB30 | Nichicon | CAP ALUM 270UF 20% 420V SNAP | 97% | View |
| ELXS421VSN271MA25S | United Chemi-Con | CAP ALUM 270UF 20% 420V SNAP | 93% | View |
| ELXS3B1VSN271MQ30S | United Chemi-Con | CAP ALUM 270UF 20% 315V SNAP | 92% | View |
| LASW6271MELC30 | Nichicon | CAP ALUM 270UF 20% 420V SNAP | 88% | View |
Submit your RFQ for LKX2G271MESB35 and get a quote within 24 hours.
