CAP ALUM 100UF 20% 400V SNAP
LKX2G101MESY35 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 100UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In.
In Stock: 4,995
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 100 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 680 mA @ 120 Hz |
| Ripple Current @ High Frequency | 972.4 mA @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.787" Dia (20.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LSM101M2G---2230S | Surge | CAP ALUM 400V POLAR | 99% | View |
| LHM101M2W---2525S | Surge | CAP ALUM 450V POLAR | 96% | View |
| ELG107M400AQ2AA | KEMET | CAP ALUM SNAP-IN 105C | 94% | View |
| ELG107M450AR2AV | KEMET | CAP ALUM SNAP-IN 105C | 91% | View |
| LSK101M2G---2230S | Surge | CAP ALUM 400V POLAR | 86% | View |
| LSG101M2W---2230S | Surge | CAP ALUM 100UF 20% 450V SNAP IN | 84% | View |
