CAP ALUM 3900UF 20% 50V SNAP
LKS1H392MESC is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 3900UF 20% 50V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 85°C, voltage - rated 50 V, package / case Radial, Can - Snap-In.
In Stock: 8,064
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 3900 µF |
| Tolerance | ±20% |
| Voltage - Rated | 50 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 1000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | Audio |
| Ripple Current @ Low Frequency | 2.3 A @ 120 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ESMH500VSN392MP35S | United Chemi-Con | CAP ALUM 3900UF 20% 50V SNAP | 95% | View |
| MAL215661392E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3900UF 20% 50V SNAP | 90% | View |
| B41605E7398M9S1 | EPCOS - TDK Electronics | CAP ALUM 3900UF 20% 40V RADIAL | 86% | View |
| 53D392F063HP6 | Vishay Sprague | CAP ALUM 3900UF 63V AXIAL | 85% | View |
| EEU-FM1A392SB | Panasonic Electronic Components | CAP ALUM 3900UF 20% 10V RADIAL | 67% | View |
| LKG1E392MESACK | Nichicon | CAP ALUM 3900UF 20% 25V SNAP | 65% | View |
Submit your RFQ for LKS1H392MESC and get a quote within 24 hours.
