CAP ALUM 3300UF 20% 80V SNAP
LGU1K332MELB is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 3300UF 20% 80V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 80 V, package / case Radial, Can - Snap-In.
In Stock: 1,383
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 3300 µF |
| Tolerance | ±20% |
| Voltage - Rated | 80 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.78 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.197 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| SLP332M063E3P3 | Cornell Dubilier Electronics (CDE) | CAP ALUM 3300UF 20% 63V SNAP | 85% | View |
| 63MXC3300MEFC25X35 | Rubycon | CAP ALUM 3300UF 20% 63V SNAP | 84% | View |
| MAL215868332E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 3300UF 20% 63V SNAP | 80% | View |
| EKMQ630ELL332MN40S | United Chemi-Con | CAP ALUM 3300UF 20% 63V RADIAL | 74% | View |
| 50PX3300MEFC18X31.5 | Rubycon | CAP ALUM 3300UF 20% 50V RADIAL | 70% | View |
| 50MXC3300MEFC25X30 | Rubycon | CAP ALUM 3300UF 20% 50V SNAP | 69% | View |
