CAP ALUM 15000UF 20% 25V SNAP
LGU1E153MELB is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 15000UF 20% 25V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 25 V, package / case Radial, Can - Snap-In.
In Stock: 3,102
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 15000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 3.13 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.5995 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 35MXC15000MEFCSN30X45 | Rubycon | CAP ALUM 15000UF 20% 35V SNAP | 78% | View |
| B41252B7159M | EPCOS - TDK Electronics | CAP ALUM 15000UF 20% 35V SNAP | 77% | View |
| MAL215875153E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 15000UF 20% 16V SNAP | 75% | View |
| MAL215865153E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 15000UF 20% 16V SNAP | 71% | View |
| 10MXC15000MEFC25X30 | Rubycon | CAP ALUM 15000UF 20% 10V SNAP | 60% | View |
| EKMH100VSN153MP30U | United Chemi-Con | CAP ALUM 15000UF 20% 10V SNAP | 55% | View |
Submit your RFQ for LGU1E153MELB and get a quote within 24 hours.
