CAP ALUM 22000UF 20% 16V SNAP
LGU1C223MELB is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 22000UF 20% 16V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 16 V, package / case Radial, Can - Snap-In.
In Stock: 8,817
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 22000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 16 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 3.39 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.8985 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 16MXC22000MEFC22X45 | Rubycon | CAP ALUM 22000UF 20% 16V SNAP | 100% | View |
| EKMH160VNN223MQ45U | United Chemi-Con | CAP ALUM 22000UF 20% 16V SNAP | 98% | View |
| EKMH250VSN223MR45U | United Chemi-Con | CAP ALUM 22000UF 20% 25V SNAP | 80% | View |
| 25MXC22000MEFC30X35 | Rubycon | CAP ALUM 22000UF 20% 25V SNAP | 78% | View |
| 229CKE010M | Cornell Dubilier / Illinois Capacitor | CAP ALUM 22000UF 20% 10V RADIAL | 74% | View |
| MAL216246223E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22000UF 20% 25V SNAP | 63% | View |
Submit your RFQ for LGU1C223MELB and get a quote within 24 hours.
