CAP ALUM 390UF 20% 420V SNAP
LGNW6391MELC35 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 390UF 20% 420V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 420 V, package / case Radial, Can - Snap-In.
In Stock: 3,856
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 390 µF |
| Tolerance | ±20% |
| Voltage - Rated | 420 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.61 A @ 120 Hz |
| Ripple Current @ High Frequency | 2.3023 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL215977391E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 390UF 20% 450V SNAP | 97% | View |
| HU2G391MCYS6WPEC | AIC tech Inc. | CAP ALUM 390UF 20% 400V SNAP | 97% | View |
| 381LQ391M450K042 | Cornell Dubilier Electronics (CDE) | CAP ALUM 390UF 20% 450V SNAP | 96% | View |
| 397LMX400M2DG | Cornell Dubilier / Illinois Capacitor | CAP ALUM 390UF 20% 400V SNAP | 95% | View |
| B43544B5397M000 | EPCOS - TDK Electronics | CAP ALUM 390UF 20% 450V SNAP | 87% | View |
| LGX2E391MELA30 | Nichicon | CAP ALUM 390UF 20% 250V SNAP | 80% | View |
Submit your RFQ for LGNW6391MELC35 and get a quote within 24 hours.
