CAP ALUM 330UF 20% 450V SNAP
LGN2W331MELC35 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 330UF 20% 450V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 450 V, package / case Radial, Can - Snap-In.
In Stock: 5,404
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.38 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.9734 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| LKX2G331MESC30 | Nichicon | CAP ALUM 330UF 20% 400V SNAP | 94% | View |
| ELHS4H1VSN331MA35S | United Chemi-Con | CAP ALUM 330UF 20% 475V SNAP | 94% | View |
| 475MXK330MEFCSN35X30 | Rubycon | CAP ALUM 330UF 20% 475V SNAP | 93% | View |
| 250VXH330MEFC25X25 | Rubycon | CAP ALUM 330UF 20% 250V SNAP | 79% | View |
| 450HXC330MEFC30X50 | Rubycon | CAP ALUM 330UF 20% 450V SNAP | 73% | View |
| 337CKE160MKCG | Cornell Dubilier / Illinois Capacitor | CAP ALUM 330UF 20% 160V RADIAL | 72% | View |
Submit your RFQ for LGN2W331MELC35 and get a quote within 24 hours.
