CAP ALUM 390UF 20% 450V SNAP
LGL2W391MELC30 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 390UF 20% 450V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 450 V, package / case Radial, Can - Snap-In.
In Stock: 1,929
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 390 µF |
| Tolerance | ±20% |
| Voltage - Rated | 450 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.28 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.8304 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.260" (32.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43544A5397M002 | EPCOS - TDK Electronics | CAP ALUM 390UF 20% 450V SNAP | 100% | View |
| B43508A9397M7 | EPCOS - TDK Electronics | CAP ALUM 390UF 20% 400V SNAP | 91% | View |
| EKMS451VSN391MA35S | United Chemi-Con | CAP ALUM 390UF 20% 450V SNAP | 86% | View |
| 400MXK390MEFCSN30X30 | Rubycon | CAP ALUM 390UF 20% 400V SNAP | 85% | View |
| LKX2E391MESA30 | Nichicon | CAP ALUM 390UF 20% 250V SNAP | 80% | View |
| B43504E2397M67 | EPCOS - TDK Electronics | CAP ALUM 390UF 20% 200V SNAP | 69% | View |
Submit your RFQ for LGL2W391MELC30 and get a quote within 24 hours.
