CAP ALUM 330UF 20% 400V SNAP
LGL2G331MELB25 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 330UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In.
In Stock: 4,412
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 330 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.04 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.4872 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.181" Dia (30.00mm) |
| Height - Seated (Max) | 1.063" (27.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43544B9337M080 | EPCOS - TDK Electronics | CAP ALUM 330UF 20% 400V SNAP | 83% | View |
| 381LQ331M450K452 | Cornell Dubilier Electronics (CDE) | CAP ALUM 330UF 20% 450V SNAP | 83% | View |
| MAL215943331E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 330UF 20% 250V SNAP | 76% | View |
| LGU2E331MELB | Nichicon | CAP ALUM 330UF 20% 250V SNAP | 74% | View |
| EL1V331MP51016U | Chinsan (Elite) | ALUMINUM ELECTROLYTIC CAPACITORS | 74% | View |
| 420HXG330MEFC35X30 | Rubycon | CAP ALUM 330UF 20% 420V SNAP | 64% | View |
Submit your RFQ for LGL2G331MELB25 and get a quote within 24 hours.
