CAP ALUM 1200UF 20% 250V SNAP
LGG2E122MELC35 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 1200UF 20% 250V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can - Snap-In.
In Stock: 1,123
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1200 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.2 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.3 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43509F2128M000 | EPCOS - TDK Electronics | CAP ALUM 1200UF 20% 250V SNAP | 95% | View |
| B43504B2128M80 | EPCOS - TDK Electronics | CAP ALUM 1200UF 20% 250V SNAP | 89% | View |
| 381LX122M180A022 | Cornell Dubilier Electronics (CDE) | CAP ALUM 1200UF 20% 180V SNAP | 88% | View |
| EET-HC2D122LA | Panasonic Electronic Components | CAP ALUM 1200UF 20% 200V SNAP | 86% | View |
| 860040780019 | Würth Elektronik | CAP ALUM 1200UF 20% 63V RADIAL | 74% | View |
| B43516C9128M080 | EPCOS - TDK Electronics | CAP ALUM 1200UF 20% 400V SNAP | 60% | View |
