CAP ALUM 1800UF 20% 200V SNAP
LGG2D182MELC35 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 1800UF 20% 200V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 200 V, package / case Radial, Can - Snap-In.
In Stock: 4,220
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1800 µF |
| Tolerance | ±20% |
| Voltage - Rated | 200 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.68 A @ 120 Hz |
| Ripple Current @ High Frequency | 4.02 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.457" (37.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43508B2188M67 | EPCOS - TDK Electronics | CAP ALUM 1800UF 20% 200V SNAP | 98% | View |
| B43504A2188M000 | EPCOS - TDK Electronics | CAP ALUM 1800UF 20% 250V SNAP | 77% | View |
| 50YXG1800MEFCGC16X40 | Rubycon | CAP ALUM 1800UF 20% 50V RADIAL | 73% | View |
| EKZN160ELL182MJ25S | United Chemi-Con | CAP ALUM 1800UF 20% 16V RADIAL | 61% | View |
| MAL219050182E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1800UF 20% 35V RADIAL | 58% | View |
| 860080378023 | Würth Elektronik | CAP ALUM 1800UF 20% 16V RADIAL | 54% | View |
