CAP ALUM 270UF 20% 400V SNAP
LAR2G271MELC25 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 270UF 20% 400V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 400 V, package / case Radial, Can - Snap-In.
In Stock: 8,701
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 270 µF |
| Tolerance | ±20% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.22 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.7446 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 0.984" (25.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL215926271E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 270UF 20% 400V SNAP | 98% | View |
| B43508B9277M60 | EPCOS - TDK Electronics | CAP ALUM 270UF 20% 400V SNAP | 98% | View |
| SLP271M420E7P3 | Cornell Dubilier Electronics (CDE) | CAP ALUM 270UF 20% 420V SNAP | 97% | View |
| ELXS421VSN271MR30S | United Chemi-Con | CAP ALUM 270UF 20% 420V SNAP | 95% | View |
| EKMS501VSN271MA40S | United Chemi-Con | CAP ALUM 270UF 20% 500V SNAP | 86% | View |
| MAL215989271E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 270UF 20% 500V SNAP | 82% | View |
Submit your RFQ for LAR2G271MELC25 and get a quote within 24 hours.
