CAP ALUM 1500UF 20% 250V SNAP
LAR2E152MELC45 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 1500UF 20% 250V SNAP. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 105°C, voltage - rated 250 V, package / case Radial, Can - Snap-In.
In Stock: 6,619
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 1500 µF |
| Tolerance | ±20% |
| Voltage - Rated | 250 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -40°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 2.5 A @ 120 Hz |
| Ripple Current @ High Frequency | 3.75 A @ 50 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 1.378" Dia (35.00mm) |
| Height - Seated (Max) | 1.772" (45.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 381LX152M200K052 | Cornell Dubilier Electronics (CDE) | CAP ALUM 1500UF 20% 200V SNAP | 92% | View |
| B43508B2158M62 | EPCOS - TDK Electronics | CAP ALUM 1500UF 20% 200V SNAP | 87% | View |
| B43505E2158M87 | EPCOS - TDK Electronics | CAP ALUM 1500UF 20% 200V SNAP | 76% | View |
| EGPA500ELL152ML35S | United Chemi-Con | CAP ALUM 1500UF 20% 50V RADIAL | 70% | View |
| EEU-TP1V152SB | Panasonic Electronic Components | CAP ALUM 1500UF 20% 35V RADIAL | 63% | View |
| MAL212026152E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 1500UF 20% 25V AXIAL | 63% | View |
Submit your RFQ for LAR2E152MELC45 and get a quote within 24 hours.
