CAP ALUM 560UF 20% 220V SNAP
LAQ2P561MELA45 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 560UF 20% 220V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 220 V, package / case Radial, Can - Snap-In.
In Stock: 248
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 560 µF |
| Tolerance | ±20% |
| Voltage - Rated | 220 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 1.6 A @ 120 Hz |
| Ripple Current @ High Frequency | 1.92 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 1.850" (47.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B43508G2567M62 | EPCOS - TDK Electronics | CAP ALUM 560UF 20% 250V SNAP | 92% | View |
| ELXM3B1VSN561MA40S | United Chemi-Con | CAP ALUM 560UF 20% 315V SNAP | 74% | View |
| LGL2W561MELB50 | Nichicon | CAP ALUM 560UF 20% 450V SNAP | 73% | View |
| KY50VB561M12X25LL | United Chemi-Con | CAP ALUM 560UF 20% 50V RADIAL | 67% | View |
| MAL215859561E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 560UF 20% 100V SNAP | 65% | View |
| 35YXH560MEFC10X23 | Rubycon | CAP ALUM 560UF 20% 35V RADIAL | 62% | View |
Submit your RFQ for LAQ2P561MELA45 and get a quote within 24 hours.
