CAP ALUM 150UF 20% 220V SNAP
LAQ2P151MELA20 is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 150UF 20% 220V SNAP. Key specifications: mounting type Through Hole, operating temperature -25°C ~ 105°C, voltage - rated 220 V, package / case Radial, Can - Snap-In.
In Stock: 8,831
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 150 µF |
| Tolerance | ±20% |
| Voltage - Rated | 220 V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 2000 Hrs @ 105°C |
| Operating Temperature | -25°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 650 mA @ 120 Hz |
| Ripple Current @ High Frequency | 780 mA @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.394" (10.00mm) |
| Size / Dimension | 0.984" Dia (25.00mm) |
| Height - Seated (Max) | 0.866" (22.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Snap-In |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 220TXW150MEFR12.5X35 | Rubycon | CAP ALUM 150UF 20% 220V RAD TH | 83% | View |
| MAL213819151E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 150UF 20% 100V AXIAL | 75% | View |
| EKMM401VSN151MA20U | United Chemi-Con | CAP ALUM 150UF 20% 400V SNAP | 68% | View |
| EEU-FS1H151LB | Panasonic Electronic Components | CAP ALUM 150UF 20% 50V RADIAL | 65% | View |
| 420MXC150MEFC22X40 | Rubycon | CAP ALUM 150UF 20% 420V SNAP | 63% | View |
| 400MXG150MEFCSN22X30 | Rubycon | CAP ALUM 150UF 20% 400V SNAP | 62% | View |
