CAP ALUM 47UF 20% 6.3V SMD
F110J476MDL is a Aluminum Electrolytic Capacitors manufactured by Nichicon. CAP ALUM 47UF 20% 6.3V SMD. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 105°C, voltage - rated 6.3 V, package / case Nonstandard SMD.
In Stock: 5,228
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Capacitance | 47 µF |
| Tolerance | ±20% |
| Voltage - Rated | 6.3 V |
| ESR (Equivalent Series Resistance) | 20mOhm @ 100kHz |
| Lifetime @ Temp. | 5000 Hrs @ 105°C |
| Operating Temperature | -55°C ~ 105°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | - |
| Ripple Current @ High Frequency | 3.5 A @ 100 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.335" L x 0.209" W (8.50mm x 5.30mm) |
| Height - Seated (Max) | 0.079" (2.00mm) |
| Surface Mount Land Size | 0.335" L x 0.209" W (8.50mm x 5.30mm) |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard SMD |
F110J476MDL is Obsolete. Consider these compatible alternatives:
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| 6.3SGV47M5X6.1 | Rubycon | CAP ALUM 47UF 20% 6.3V SMD | 100% | View |
| EEE-FP0J470AR | Panasonic Electronic Components | CAP ALUM 47UF 20% 6.3V SMD | 64% | View |
| AVEZ476M06C12T-F | Cornell Dubilier Electronics (CDE) | CAP ALUM 47UF 20% 6.3V SMD | 64% | View |
| MAL214097801E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 47UF 20% 63V SMD | 56% | View |
| MAL215376479E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 47UF 20% 25V SMD | 56% | View |
| EMVY350ADA470MHA0G | United Chemi-Con | CAP ALUM 47UF 20% 35V SMD | 56% | View |
