90-305VAC, 75W CC/CP LED DRIVER
LUB075M-108C is a LED Drivers manufactured by NetPower. 90-305VAC, 75W CC/CP LED DRIVER. Key specifications: operating temperature -40°C ~ 90°C, voltage - output 54 ~ 108V, current - output (max) 1.05A, size / dimension 5.06" L x 2.68" W x 1.46" H (128.6mm x 68.0mm x 37.0mm).
In Stock: 5
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Constant Current |
| Topology | AC DC Converter |
| Number of Outputs | 1 |
| Voltage - Input (Min) | 90VAC |
| Voltage - Input (Max) | 305VAC |
| Voltage - Output | 54 ~ 108V |
| Current - Output (Max) | 1.05A |
| Power (Watts) | 75 W |
| Voltage - Isolation | 3.75 kV |
| Dimming | Analog, PWM |
| Features | OTP, OVP, SCP |
| Ratings | IP67 |
| Operating Temperature | -40°C ~ 90°C |
| Efficiency | 90% |
| Termination Style | Wire Leads |
| Size / Dimension | 5.06" L x 2.68" W x 1.46" H (128.6mm x 68.0mm x 37.0mm) |
| Approval Agency | CE, cURus |
| Standard Number | - |
Submit your RFQ for LUB075M-108C and get a quote within 24 hours.
