FIXED IND 68MH 26MA 242 OHM SMD
22R686MC is a Fixed Inductors manufactured by Murata Power Solutions Inc.. FIXED IND 68MH 26MA 242 OHM SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, package / case Nonstandard, current rating (amps) 26 mA.
In Stock: 187,740
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 68 mH |
| Tolerance | ±10% |
| Current Rating (Amps) | 26 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 242Ohm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 85°C |
| Inductance Frequency - Test | 1 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.307" L x 0.276" W (7.80mm x 7.00mm) |
| Height - Seated (Max) | 0.311" (7.90mm) |
Submit your RFQ for 22R686MC and get a quote within 24 hours.
