AC/DC DIN RAIL SUPPLY 48V 36W
LI30-20B48PR2 is a Industrial, DIN Rail Power Supplies manufactured by Mornsun America, LLC. AC/DC DIN RAIL SUPPLY 48V 36W. Key specifications: operating temperature -40°C ~ 70°C (With Derating), current - output (max) 750mA, size / dimension 2.28" L x 1.38" W x 3.65" H (58.0mm x 35.0mm x 92.7mm), number of outputs 1.
In Stock: 74
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC or DC |
| Number of Outputs | 1 |
| AC Voltage - Input | 85 ~ 264 VAC |
| DC Voltage - Input (Min) | 120V |
| DC Voltage - Input (Max) | 370V |
| Voltage - Output 1 | 48V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 750mA |
| Power (Watts) | 36W |
| Voltage - Isolation | 4 kV |
| Applications | ITE (Commercial) |
| Efficiency | 90% |
| Operating Temperature | -40°C ~ 70°C (With Derating) |
| Features | Adjustable Output, Standby Output, Universal Input |
| Size / Dimension | 2.28" L x 1.38" W x 3.65" H (58.0mm x 35.0mm x 92.7mm) |
| Approval Agency | CB, CE, cURus |
| Standard Number | 62368-1 |
Submit your RFQ for LI30-20B48PR2 and get a quote within 24 hours.
