AC/DC CONVERTER 15V 10W
LD10-23B15R2 is a AC DC Converters manufactured by Mornsun America, LLC. AC/DC CONVERTER 15V 10W. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C (With Derating), voltage - input 85 ~ 305 VAC, 100 ~ 430 VDC, package / case 10-SMD Module, 6 Leads.
In Stock: 133
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Enclosed |
| Number of Outputs | 1 |
| Voltage - Input | 85 ~ 305 VAC, 100 ~ 430 VDC |
| Voltage - Output 1 | 15V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Current - Output (Max) | 660mA |
| Power (Watts) | 10 W |
| Applications | Household Appliances, ITE (Commercial) |
| Features | Adjustable Output |
| Operating Temperature | -40°C ~ 85°C (With Derating) |
| Efficiency | 84% |
| Mounting Type | Surface Mount |
| Package / Case | 10-SMD Module, 6 Leads |
| Size / Dimension | 1.57" L x 1.00" W x 0.83" H (40.0mm x 25.4mm x 21.0mm) |
| Approval Agency | CB, CE, cURus, UL |
| Standard Number | 60335-1; 62368-1 |
