ZERO-HACHI 0.8 HDR SR RA ETP SN
2147210020 is a Rectangular Connectors - Headers, Receptacles, Female Sockets manufactured by Molex. ZERO-HACHI 0.8 HDR SR RA ETP SN. Key specifications: mounting type Surface Mount, Right Angle, operating temperature -40°C ~ 85°C, voltage rating 30V, current rating (amps) 1.5A.
In Stock: 40,000
| Attribute | Value |
|---|---|
| Product Status | Active |
| Connector Type | Header |
| Contact Type | Forked |
| Style | Board to Cable/Wire |
| Number of Positions | 2 |
| Number of Positions Loaded | All |
| Pitch - Mating | 0.031" (0.80mm) |
| Number of Rows | 1 |
| Row Spacing - Mating | - |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | Detent Lock |
| Contact Finish - Mating | Tin |
| Contact Finish Thickness - Mating | 39.4µin (1.00µm) |
| Insulation Color | Black |
| Insulation Height | 0.063" (1.60mm) |
| Contact Length - Post | - |
| Operating Temperature | -40°C ~ 85°C |
| Material Flammability Rating | UL94 V-0 |
| Contact Finish - Post | Tin |
| Mated Stacking Heights | - |
| Ingress Protection | - |
| Features | Solder Retention |
| Current Rating (Amps) | 1.5A |
| Voltage Rating | 30V |
Submit your RFQ for 2147210020 and get a quote within 24 hours.
