CONN D-SUB PLUG 17POS SLDR CUP
1731140087 is a D-Sub Connectors manufactured by Molex. CONN D-SUB PLUG 17POS SLDR CUP. Key specifications: mounting type Free Hanging (In-Line), current rating (amps) 5A, 20A, termination Solder Cup, number of positions 17 (15 + 2 Power).
In Stock: 11
| Attribute | Value |
|---|---|
| Product Status | Active |
| Connector Style | D-Sub, Combo |
| Connector Type | Plug, Male Pins |
| Number of Positions | 17 (15 + 2 Power) |
| Number of Rows | 2 |
| Mounting Type | Free Hanging (In-Line) |
| Shell Size, Connector Layout | 3 (DB, B) - 17W2 |
| Contact Type | Signal and Power |
| Flange Feature | Housing/Shell (Unthreaded) |
| Termination | Solder Cup |
| Primary Material | - |
| Shell Material, Finish | Steel, Tin Plated |
| Contact Finish | Gold |
| Contact Finish Thickness | 4.00µin (0.100µm) |
| Ingress Protection | - |
| Material Flammability Rating | UL94 V-0 |
| Current Rating (Amps) | 5A, 20A |
| Backset Spacing | - |
| Features | Backshell, Cable Clamp, Grounding Indents, Mounting Hardware, Strain Relief |
