MOSFET P-CH 20V 630MA TO243AA
TP2502N8-G is a Transistors - FETs, MOSFETs - Single manufactured by Microchip Technology. MOSFET P-CH 20V 630MA TO243AA. Key specifications: mounting type Surface Mount, operating temperature -55°C ~ 150°C (TJ), package / case TO-243AA.
In Stock: 1,031
| Attribute | Value |
|---|---|
| Product Status | Active |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 630mA (Tj) |
| Drive Voltage (Max Rds On, Min Rds On) | 5V, 10V |
| Rds On (Max) @ Id, Vgs | 2Ohm @ 1A, 10V |
| Vgs(th) (Max) @ Id | 2.4V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | - |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 125 pF @ 20 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.6W (Ta) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-243AA (SOT-89) |
| Package / Case | TO-243AA |
Submit your RFQ for TP2502N8-G and get a quote within 24 hours.
