AC/DC CONVERTER 24V 60W
WDR-60-24 is a Industrial, DIN Rail Power Supplies manufactured by MEAN WELL USA Inc.. AC/DC CONVERTER 24V 60W. Key specifications: operating temperature -30°C ~ 85°C (With Derating), current - output (max) 2.5A, size / dimension 4.02" L x 1.26" W x 4.93" H (102.0mm x 32.0mm x 125.2mm), number of outputs 1.
In Stock: 8,288
| Attribute | Value |
|---|---|
| Product Status | Active |
| Input Type | AC or DC |
| Number of Outputs | 1 |
| AC Voltage - Input | 180 ~ 550 VAC |
| DC Voltage - Input (Min) | 254V |
| DC Voltage - Input (Max) | 780V |
| Voltage - Output 1 | 24V |
| Voltage - Output 2 | - |
| Voltage - Output 3 | - |
| Voltage - Output 4 | - |
| Voltage - Output 5 | - |
| Voltage - Output 6 | - |
| Current - Output (Max) | 2.5A |
| Power (Watts) | 60W |
| Voltage - Isolation | 4.7 kV |
| Applications | Laboratory |
| Efficiency | 89% |
| Operating Temperature | -30°C ~ 85°C (With Derating) |
| Features | Adjustable Output |
| Size / Dimension | 4.02" L x 1.26" W x 4.93" H (102.0mm x 32.0mm x 125.2mm) |
| Approval Agency | CE, EAC, TUV, UL |
| Standard Number | - |
Submit your RFQ for WDR-60-24 and get a quote within 24 hours.
