AC/DC WALL MOUNT ADAPTER 5V 12W
GS15U-1P1J is a AC DC Desktop, Wall Adapters manufactured by MEAN WELL USA Inc.. AC/DC WALL MOUNT ADAPTER 5V 12W. Key specifications: operating temperature 0°C ~ 50°C, voltage - input 90 ~ 264 VAC, current - output (max) 2.4A, size / dimension 2.80" L x 1.34" W x 1.97" H (71.0mm x 34.0mm x 50.0mm).
In Stock: 96
| Attribute | Value |
|---|---|
| Product Status | Obsolete |
| Region Utilized | North America |
| Form | Wall Mount (Class II) |
| Input Type | Fixed Blade |
| Voltage - Input | 90 ~ 264 VAC |
| Voltage - Output | 5V |
| Current - Output (Max) | 2.4A |
| Power (Watts) | 12 W |
| No Load Power Consumption | 75mW (Max) |
| Polarization | Positive Center |
| Applications | ITE (Commercial) |
| Efficiency | Level VI |
| Operating Temperature | 0°C ~ 50°C |
| Output Connector | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11.0mm |
| Cord Length | 47.2" (1.20m) |
| Input Connector | NEMA 1-15P |
| Features | - |
| Size / Dimension | 2.80" L x 1.34" W x 1.97" H (71.0mm x 34.0mm x 50.0mm) |
| Approval Agency | CE, cULus |
| Standard Number | - |
Submit your RFQ for GS15U-1P1J and get a quote within 24 hours.
