Mallory Sonalert Products Inc.
BUZZER MAGN 1.5V 31X17MM FLANGE
PK-16N04WA-01Q is a Alarms, Buzzers, and Sirens manufactured by Mallory Sonalert Products Inc.. BUZZER MAGN 1.5V 31X17MM FLANGE. Key specifications: mounting type Panel Mount, Flange, operating temperature -20°C ~ 70°C, voltage - rated 1.5 V, current - supply 30mA.
In Stock: 9,918
| Attribute | Value |
|---|---|
| Product Status | Active |
| Driver Circuitry | Indicator, Internally Driven |
| Input Type | DC |
| Voltage - Rated | 1.5 V |
| Voltage Range | 1.5 ~ 2V |
| Frequency | 400Hz |
| Technology | Magnetic |
| Operating Mode | Single Tone |
| Duration | - |
| Sound Pressure Level (SPL) | 75dB @ 1.5V, 30cm |
| Current - Supply | 30mA |
| Port Location | Top |
| Operating Temperature | -20°C ~ 70°C |
| Approval Agency | - |
| Ratings | - |
| Ingress Protection | - |
| Mounting Type | Panel Mount, Flange |
| Termination | Wire Leads |
| Size / Dimension | 1.220" L x 0.669" W (31.00mm x 17.00mm) |
| Height - Seated (Max) | 0.602" (15.30mm) |
Submit your RFQ for PK-16N04WA-01Q and get a quote within 24 hours.
