LXZ1-PD01 - Lumileds - LED Lighting - Color

LXZ1-PD01

Lumileds

LED LUXEON Z RED 633NM SMD

LXZ1-PD01 is a LED Lighting - Color manufactured by Lumileds. LED LUXEON Z RED 633NM SMD. Key specifications: mounting type Surface Mount, voltage - forward (vf) (typ) 2.2V, package / case 0705 (1713 Metric), color Red.

In Stock: 11,810

Product Attributes

AttributeValue
Product StatusActive
ColorRed
Wavelength633nm (620nm ~ 645nm)
Current - Test500mA
Voltage - Forward (Vf) (Typ)2.2V
Lumens/Watt @ Current - Test44 lm/W
Current - Max700mA
Luminous Flux @ Current/Temperature48lm (40lm ~ 56lm)
Temperature - Test25°C
Viewing Angle145°
Mounting TypeSurface Mount
Package / Case0705 (1713 Metric)
Supplier Device PackageSMD
Size / Dimension0.067" L x 0.051" W (1.70mm x 1.30mm)
Height - Seated (Max)0.026" (0.66mm)

Frequently Asked Questions

LXZ1-PD01 is a LED Lighting - Color manufactured by Lumileds. LED LUXEON Z RED 633NM SMD

The mounting type of LXZ1-PD01 is Surface Mount.

The supply voltage of LXZ1-PD01 is 2.2V.

The package type of LXZ1-PD01 is 0705 (1713 Metric).

The wavelength of LXZ1-PD01 is 633nm (620nm ~ 645nm).
