PTC RESET FUSE 250V 250MA 4SMD
TSM600-250F-2 is a PTC Resettable Fuses manufactured by Littelfuse Inc.. PTC RESET FUSE 250V 250MA 4SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 85°C, package / case 4-SMD, current - max 3 A.
In Stock: 777
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Polymeric |
| Voltage - Max | 250V (600V Int) |
| Current - Max | 3 A |
| Current - Hold (Ih) (Max) | 250 mA |
| Current - Trip (It) | 860 mA |
| Time to Trip | 6 s |
| Resistance - Initial (Ri) (Min) | 1 Ohms |
| Resistance - Post Trip (R1) (Max) | 7 Ohms |
| Resistance - 25°C (Typ) | - |
| Operating Temperature | -40°C ~ 85°C |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD |
| Size / Dimension | 0.681" L x 0.425" W (17.30mm x 10.80mm) |
| Height - Seated (Max) | - |
| Thickness (Max) | 0.461" (11.70mm) |
| Lead Spacing | - |
