ANT OMNI DBAND 30CM DINF
CFS69383P-30D43F is a RF Antennas manufactured by TE Connectivity Laird. ANT OMNI DBAND 30CM DINF. Key specifications: mounting type Panel Mount, termination 4.3/10 - Female, power - max 50 W, frequency range 698MHz ~ 960MHz, 1.35GHz ~ 1.55GHz, 1.69GHz ~ 3.8GHz.
In Stock: 100
| Attribute | Value |
|---|---|
| Product Status | Active |
| RF Family/Standard | Cellular, WiFi |
| Frequency Group | Wide Band |
| Frequency (Center/Band) | 752MHz, 859MHz, 920MHz, 1.45GHz, 1.785GHz, 1.92GHz, 2.04GHz, 2.4GHz, 2.6GHz, 3.55GHz |
| Frequency Range | 698MHz ~ 960MHz, 1.35GHz ~ 1.55GHz, 1.69GHz ~ 3.8GHz |
| Antenna Type | Flat Panel |
| Number of Bands | 10 |
| VSWR | 1.8, 2 |
| Return Loss | - |
| Gain | 3.5dBi, 3.9dBi, 4.8dBi, 4.8dBi, 4.4dBi, 4.5dBi, 4.4dBi, 4.9dBi, 5.4dBi, 4.8dBi |
| Power - Max | 50 W |
| Features | Cable - 300mm |
| Termination | 4.3/10 - Female |
| Ingress Protection | - |
| Mounting Type | Panel Mount |
| Height (Max) | 0.300" (7.62mm) |
| Applications | AWS, GSM, DCS, LTE, UMTS, WiMax™ |
Submit your RFQ for CFS69383P-30D43F and get a quote within 24 hours.
