FIXED IND 600UH 20MOHM CHAS MNT
SNG-25B-600 is a Fixed Inductors manufactured by KEMET. FIXED IND 600UH 20MOHM CHAS MNT. Key specifications: mounting type Chassis Mount, operating temperature -25°C ~ 105°C, package / case Vertical, 2 Wire Leads, size / dimension 1.929" L x 0.945" W (49.00mm x 24.00mm).
In Stock: 116
| Attribute | Value |
|---|---|
| Product Status | Active |
| Type | Drum Core, Wirewound |
| Material - Core | Manganese Zinc Ferrite (MnZn) |
| Inductance | 600 µH |
| Tolerance | -30%, +50% |
| Current Rating (Amps) | - |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 20mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -25°C ~ 105°C |
| Inductance Frequency - Test | 160 kHz |
| Features | - |
| Mounting Type | Chassis Mount |
| Package / Case | Vertical, 2 Wire Leads |
| Supplier Device Package | - |
| Size / Dimension | 1.929" L x 0.945" W (49.00mm x 24.00mm) |
| Height - Seated (Max) | 1.535" (39.00mm) |
Submit your RFQ for SNG-25B-600 and get a quote within 24 hours.
