CAP FILM 0.068UF 5% 2KVDC RADIAL
PHE450SF5680JR06L2 is a Film Capacitors manufactured by KEMET. CAP FILM 0.068UF 5% 2KVDC RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage rating - dc 2000V (2kV), package / case Radial.
In Stock: 1,566
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 0.068 µF |
| Tolerance | ±5% |
| Voltage Rating - AC | 700V |
| Voltage Rating - DC | 2000V (2kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | - |
| Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 1.240" L x 0.413" W (31.50mm x 10.50mm) |
| Height - Seated (Max) | 0.807" (20.50mm) |
| Termination | PC Pins |
| Lead Spacing | 1.083" (27.50mm) |
| Applications | High Frequency, Switching |
| Ratings | - |
| Features | - |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MKP385368160JIM2T0 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.068UF 5% 1.6KVDC RAD | 94% | View |
| R76QN2680JB30J | KEMET | CAP FILM AUTO POLYPROP RAD | 88% | View |
| PVC10168 | Cornell Dubilier Electronics (CDE) | CAP FILM 0.068UF 10% 1KVDC RAD | 73% | View |
| MKP383368040JFM2B0 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 0.068UF 5% 400VDC RAD | 60% | View |
| R75MD2680JEA0J | KEMET | CAP FILM AUTO POLYPROP RAD | 60% | View |
| R75MD2680AAA0J | KEMET | CAP FILM AUTO POLYPROP RAD | 60% | View |
Submit your RFQ for PHE450SF5680JR06L2 and get a quote within 24 hours.
