CAP FILM 4700PF 5% 2KVDC RADIAL
PHE450SB4470JR06 is a Film Capacitors manufactured by KEMET. CAP FILM 4700PF 5% 2KVDC RADIAL. Key specifications: mounting type Through Hole, operating temperature -55°C ~ 105°C, voltage rating - dc 2000V (2kV), package / case Radial.
In Stock: 7,623
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 4700 pF |
| Tolerance | ±5% |
| Voltage Rating - AC | 700V |
| Voltage Rating - DC | 2000V (2kV) |
| Dielectric Material | Polypropylene (PP), Metallized |
| ESR (Equivalent Series Resistance) | - |
| Operating Temperature | -55°C ~ 105°C |
| Mounting Type | Through Hole |
| Package / Case | Radial |
| Size / Dimension | 0.709" L x 0.217" W (18.00mm x 5.50mm) |
| Height - Seated (Max) | 0.413" (10.50mm) |
| Termination | PC Pins |
| Lead Spacing | 0.591" (15.00mm) |
| Applications | High Frequency, Switching |
| Ratings | - |
| Features | - |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| B32672L8472J289 | EPCOS - TDK Electronics | CAP FILM 4700PF 5% 2KVDC RADIAL | 100% | View |
| MKP385247250JIP2T0 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 4700PF 5% 2.5KVDC RAD | 93% | View |
| BFC237530472 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 4700PF 5% 1.6KVDC RAD | 92% | View |
| MKP385247100JCA2B0 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 4700PF 5% 1KVDC RADIAL | 81% | View |
| BFC233868164 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 4700PF 10% 1KVDC RADIAL | 79% | View |
| BFC233913472 | Vishay Beyschlag/Draloric/BC Components | CAP FILM 4700PF 10% 630VDC RAD | 73% | View |
Submit your RFQ for PHE450SB4470JR06 and get a quote within 24 hours.
