ALUMINUM ELECTROLYTIC, RADIAL CR
PEH227HLL4430QE4 is a Aluminum Electrolytic Capacitors manufactured by KEMET. ALUMINUM ELECTROLYTIC, RADIAL CR. Key specifications: mounting type Through Hole, operating temperature -40°C ~ 125°C, voltage - rated 25 V, package / case Radial, Can - Solder Lug.
In Stock: 3,206
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 4300 µF |
| Tolerance | -10%, +30% |
| Voltage - Rated | 25 V |
| ESR (Equivalent Series Resistance) | 37mOhm @ 100Hz |
| Lifetime @ Temp. | 2000 Hrs @ 150°C |
| Operating Temperature | -40°C ~ 125°C |
| Polarization | Polar |
| Ratings | AEC-Q200 |
| Applications | Automotive |
| Ripple Current @ Low Frequency | 2.45 A @ 100 Hz |
| Ripple Current @ High Frequency | 7 A @ 5 kHz |
| Impedance | - |
| Lead Spacing | - |
| Size / Dimension | 0.717" Dia (18.20mm) |
| Height - Seated (Max) | 1.130" (28.70mm) |
| Surface Mount Land Size | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Can - Solder Lug |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| EGXF250ELL432MK35S | United Chemi-Con | CAP ALUM 4300UF 20% 25V RAD TH | 99% | View |
| EGXF250ELL432ML25S | United Chemi-Con | CAP ALUM 4300UF 20% 25V RAD TH | 98% | View |
| EGXF350ELL432ML35S | United Chemi-Con | CAP ALUM 4300UF 20% 35V RAD TH | 83% | View |
| EGXF250ELL432MM20S | United Chemi-Con | CAP ALUM 4300UF 20% 25V RAD TH | 83% | View |
| EGPD250ELL432MM20H | United Chemi-Con | CAP ALUM 4300UF 20% 25V RADIAL | 82% | View |
| UBY1E432MHL | Nichicon | CAP ALUM 4300UF 20% 25V RADIAL | 82% | View |
