CAP ALUM 22000UF 20% 63V SCREW
PEH200MJ5220MB2 is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 22000UF 20% 63V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 63 V, package / case Radial, Can - Screw Terminals.
In Stock: 8,138
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 22000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 63 V |
| ESR (Equivalent Series Resistance) | 10mOhm @ 100Hz |
| Lifetime @ Temp. | 12000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 19 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 8 mOhms |
| Lead Spacing | 0.866" (22.00mm) |
| Size / Dimension | 2.032" Dia (51.60mm) |
| Height - Seated (Max) | 3.799" (96.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL210149223E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22000UF 20% 100V SCREW | 77% | View |
| B41458B8229M000 | EPCOS - TDK Electronics | CAP ALUM 22000UF 20% 63V SCREW | 74% | View |
| MAL210657223E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 22000UF 40V SCREW | 71% | View |
| 63LSW22000MNB51X83 | Rubycon | CAP ALUM 22000UF 20% 63V SCREW | 70% | View |
| ALS81H223QM200 | KEMET | CAP ALUM 22000UF 20% 200V SCREW | 64% | View |
| LNT1K223MSE | Nichicon | CAP ALUM 22000UF 20% 80V SCREW | 64% | View |
Submit your RFQ for PEH200MJ5220MB2 and get a quote within 24 hours.
