CAP ALUM 15000UF 20% 40V SCREW
PEH200KC5150MB2 is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 15000UF 20% 40V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 40 V, package / case Radial, Can - Screw Terminals.
In Stock: 3,651
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 15000 µF |
| Tolerance | ±20% |
| Voltage - Rated | 40 V |
| ESR (Equivalent Series Resistance) | 16mOhm @ 100Hz |
| Lifetime @ Temp. | 10000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 14.6 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 12 mOhms |
| Lead Spacing | 0.512" (13.00mm) |
| Size / Dimension | 1.441" Dia (36.60mm) |
| Height - Seated (Max) | 2.933" (74.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ALS31A153DB040 | KEMET | CAP ALUM 15000UF 20% 40V SCREW | 86% | View |
| MAL210616153E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 15000UF 25V SCREW | 60% | View |
| LNT1V153MSEN | Nichicon | CAP ALUM 15000UF 20% 35V SCREW | 60% | View |
| MAL210413153E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 15000UF 20% 250V SCREW | 56% | View |
| B43455A4159M3 | EPCOS - TDK Electronics | CAP ALUM 15000UF 20% 350V SCREW | 54% | View |
| LNT1J153MSEN | Nichicon | CAP ALUM 15000UF 20% 63V SCREW | 52% | View |
