CAP ALUM 470UF 400V SCREW
PEH169VH3470QB2 is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 470UF 400V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 400 V, package / case Radial, Can - Screw Terminals.
In Stock: 8,127
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 470 µF |
| Tolerance | -10%, +30% |
| Voltage - Rated | 400 V |
| ESR (Equivalent Series Resistance) | 160mOhm @ 100Hz |
| Lifetime @ Temp. | 5000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 4 A @ 100 Hz |
| Ripple Current @ High Frequency | 13.5 A @ 10 kHz |
| Impedance | - |
| Lead Spacing | 0.866" (22.00mm) |
| Size / Dimension | 2.031" Dia (51.60mm) |
| Height - Seated (Max) | 2.933" (74.50mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| MAL210256471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 400V SCREW | 92% | View |
| MAL210227471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 450V SCREW | 90% | View |
| MAL210417471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 450V SCREW | 89% | View |
| MAL210265471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 350V SCREW | 86% | View |
| MAL210225471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 350V SCREW | 86% | View |
| MAL210415471E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 470UF 20% 350V SCREW | 80% | View |
