CAP ALUM 4700UF 20% 160V SCREW
PEH169QO447VMB2 is a Aluminum Electrolytic Capacitors manufactured by KEMET. CAP ALUM 4700UF 20% 160V SCREW. Key specifications: mounting type Chassis Mount, operating temperature -40°C ~ 85°C, voltage - rated 160 V, package / case Radial, Can - Screw Terminals.
In Stock: 8,199
| Attribute | Value |
|---|---|
| Product Status | Active |
| Capacitance | 4700 µF |
| Tolerance | ±20% |
| Voltage - Rated | 160 V |
| ESR (Equivalent Series Resistance) | 31mOhm @ 100Hz |
| Lifetime @ Temp. | 18500 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | Polar |
| Ratings | - |
| Applications | General Purpose |
| Ripple Current @ Low Frequency | 10.9 A @ 100 Hz |
| Ripple Current @ High Frequency | - |
| Impedance | 17 mOhms |
| Lead Spacing | 1.122" (28.50mm) |
| Size / Dimension | 2.622" Dia (66.60mm) |
| Height - Seated (Max) | 4.299" (109.20mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
| Part Number | Manufacturer | Description | Match | |
|---|---|---|---|---|
| ALS70H472KE200 | KEMET | CAP ALUM 4700UF 20% 200V SCREW | 71% | View |
| ALS81U472NF450 | KEMET | CAP ALUM 4700UF 20% 450V SCREW | 65% | View |
| ALS80G472NF450 | KEMET | CAP ALUM 4700UF 20% 450V SCREW | 65% | View |
| MAL210238472E3 | Vishay Beyschlag/Draloric/BC Components | CAP ALUM 4700UF 20% 385V SCREW | 64% | View |
| LNUN7472MSEH | Nichicon | CAP ALUM 4700UF 20% 525V SCREW | 61% | View |
| B43761A6478M000 | EPCOS - TDK Electronics | CAP ALUM 4700UF 20% 500V SCREW | 60% | View |
Submit your RFQ for PEH169QO447VMB2 and get a quote within 24 hours.
