FIXED IND 47UH 480MA 670MOHM SMD
L1210R470MDWIT is a Fixed Inductors manufactured by KEMET. FIXED IND 47UH 480MA 670MOHM SMD. Key specifications: mounting type Surface Mount, operating temperature -40°C ~ 105°C, package / case 1210 (3225 Metric), current rating (amps) 480 mA.
In Stock: 18,933
| Attribute | Value |
|---|---|
| Product Status | Last Time Buy |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 47 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 480 mA |
| Current - Saturation (Isat) | 390mA |
| Shielding | - |
| DC Resistance (DCR) | 670mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | 10MHz |
| Ratings | - |
| Operating Temperature | -40°C ~ 105°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 1210 (3225 Metric) |
| Supplier Device Package | - |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Height - Seated (Max) | 0.106" (2.70mm) |
Submit your RFQ for L1210R470MDWIT and get a quote within 24 hours.
